Routing & Reliability

About

Prism’s routing layer distributes requests across multiple providers and models for reliability and performance. If one provider is down or slow, traffic automatically shifts to healthy alternatives. This ensures your application stays responsive even when individual providers experience outages or rate limiting.

When to use

• High availability: Automatic failover to backup providers when primary is down or rate-limited
• Cost optimization: Route to the cheapest provider that supports the requested model
• Latency reduction: Route to the fastest provider based on recent response times
• Traffic distribution: Split traffic across providers by weight for capacity management

Key concepts

Configuration parameters

These parameters appear in the JSON configuration blocks throughout this page.

Failover:

Retries:

Circuit breaker:

Timeouts:

Routing strategies

Configuring a routing policy

from prism import Prism

client = Prism(
    api_key="sk-prism-your-key",
    base_url="https://gateway.futureagi.com",
    control_plane_url="https://api.futureagi.com",
)

# Create a weighted routing policy
policy = client.routing.create(
    name="Production routing",
    strategy="weighted",
    config={"weights": {"openai": 70, "anthropic": 30}},
    description="70/30 split between OpenAI and Anthropic",
)

# List all routing policies
policies = client.routing.list()

# Update an existing policy
client.routing.update(
    policy["id"],
    strategy="least-latency",
    config={"providers": ["openai", "anthropic", "gemini"], "failover_on": [429, 500, 502, 503, 504]},
)

import { Prism } from "@futureagi/prism";

const client = new Prism({
  apiKey: "sk-prism-your-key",
  baseUrl: "https://gateway.futureagi.com",
  controlPlaneUrl: "https://api.futureagi.com",
});

const policy = await client.routing.create({
  name: "Production routing",
  strategy: "weighted",
  config: { weights: { openai: 70, anthropic: 30 } },
  description: "70/30 split between OpenAI and Anthropic",
});

const policies = await client.routing.list();

await client.routing.update(policy.id, {
  strategy: "least-latency",
  config: { providers: ["openai", "anthropic", "gemini"], failoverOn: [429, 500, 502, 503, 504] },
});

Failover

Failover triggers on specific HTTP status codes and error conditions: 429 (rate limit), 5xx (server errors), timeouts, and connection errors. The providers array defines the failover order. When the primary provider fails, Prism automatically routes to the next provider in the list.

{
  "failover": {
    "enabled": true,
    "providers": ["openai", "anthropic", "gemini"],
    "failover_on": [429, 500, 502, 503, 504]
  }
}

Retries

Prism uses exponential backoff for retries. This means it waits progressively longer between each retry attempt. For example, 100ms, then 200ms, then 400ms. This gives struggling providers time to recover instead of flooding them with rapid retry requests.

{
  "retries": {
    "max_retries": 3,
    "initial_backoff_ms": 100,
    "max_backoff_ms": 10000,
    "backoff_multiplier": 2
  }
}

Circuit breaking

Circuit breaking stops sending requests to a provider that is failing repeatedly. After a cooldown, Prism tests the provider with a few trial requests. If those succeed, normal routing resumes. This prevents a single failing provider from degrading your entire application.

The circuit breaker has three states:

{
  "circuit_breaker": {
    "enabled": true,
    "error_threshold_percent": 50,
    "min_requests": 10,
    "open_duration_seconds": 60,
    "half_open_max_requests": 3
  }
}

Timeouts

Configure per-request and per-provider timeouts to prevent hanging requests.

{
  "timeouts": {
    "request_timeout_seconds": 30,
    "provider_timeout_seconds": 25
  }
}

Example: High-availability setup

This configuration combines weighted routing, failover, retries, and circuit breaking for a production setup:

{
  "name": "Production HA",
  "strategy": "weighted",
  "config": {
    "weights": {
      "openai": 60,
      "anthropic": 30,
      "gemini": 10
    },
    "failover": {
      "enabled": true,
      "providers": ["openai", "anthropic", "gemini"],
      "failover_on": [429, 500, 502, 503, 504]
    },
    "retries": {
      "max_retries": 3,
      "initial_backoff_ms": 100,
      "max_backoff_ms": 10000,
      "backoff_multiplier": 2
    },
    "circuit_breaker": {
      "enabled": true,
      "error_threshold_percent": 50,
      "min_requests": 10,
      "open_duration_seconds": 60,
      "half_open_max_requests": 3
    },
    "timeouts": {
      "request_timeout_seconds": 30,
      "provider_timeout_seconds": 25
    }
  }
}

Conditional routing

Route requests to specific providers based on request attributes. Rules are evaluated in priority order (lower number = higher priority). First match wins.

Supported fields: model, user, stream, provider, session_id, request_id, metadata.<key>

Supported operators: $eq, $ne, $in, $nin, $regex, $gt, $lt, $gte, $lte, $exists

routing:
  conditional_routes:
    - name: "enterprise-to-dedicated"
      priority: 10
      condition:
        field: "metadata.tier"
        op: "$eq"
        value: "enterprise"
      action:
        provider: "openai-dedicated"

    - name: "gpt-models-to-openai"
      priority: 50
      condition:
        field: "model"
        op: "$regex"
        value: "^gpt-"
      action:
        provider: "openai"

    - name: "streaming-to-groq"
      priority: 60
      condition:
        field: "stream"
        op: "$eq"
        value: true
      action:
        provider: "groq"

You can also combine conditions with $and, $or, and $not:

    - name: "premium-non-streaming"
      priority: 20
      condition:
        $and:
          - field: "metadata.tier"
            op: "$eq"
            value: "premium"
          - field: "stream"
            op: "$eq"
            value: false
      action:
        provider: "openai-premium"

Real-world patterns

Gradual provider migration

Migrate from one provider to another without a big-bang switch. Start with 10% traffic to the new provider and increase over time:

{
  "name": "Gradual migration to Anthropic",
  "strategy": "weighted",
  "config": {
    "weights": {
      "openai": 90,
      "anthropic": 10
    }
  }
}

Increase the Anthropic weight over days or weeks. If issues arise, dial it back immediately.

Cost optimization across tiers

Use conditional routing to direct different request types to the most cost-effective provider:

routing:
  conditional_routes:
    - name: "long-context-to-gemini"
      priority: 10
      condition:
        field: "model"
        op: "$in"
        value: ["gpt-4o", "claude-opus-4-6"]
      action:
        provider: "gemini"        # Lower cost for long-context tasks

    - name: "fast-tasks-to-groq"
      priority: 20
      condition:
        field: "metadata.task_type"
        op: "$eq"
        value: "classification"
      action:
        provider: "groq"          # High speed, low cost for simple tasks

Rate limit absorption

Spread load across providers so a single rate limit doesn’t block your application:

{
  "name": "Rate limit absorption",
  "strategy": "round-robin",
  "config": {
    "providers": ["openai", "anthropic", "gemini"],
    "failover": {
      "enabled": true,
      "providers": ["openai", "anthropic", "gemini"],
      "failover_on": [429, 500, 502, 503, 504]
    }
  }
}

When OpenAI rate-limits you, traffic automatically shifts to Anthropic and Gemini.

Model fallbacks

Configure per-model fallback chains for automatic failover when a specific model is unavailable:

routing:
  model_fallbacks:
    gpt-4o:
      - claude-sonnet-4-6
      - gemini-2.0-pro
    claude-sonnet-4-6:
      - gpt-4o
      - gemini-2.0-pro

When gpt-4o fails, Prism automatically tries claude-sonnet-4-6, then gemini-2.0-pro.

Complexity-based routing

Route requests to different models based on prompt complexity. Prism scores each request on 8 signals and maps it to a tier.

Scoring signals:

Each signal produces a 0-100 score. The weighted sum maps to a tier:

routing:
  complexity:
    enabled: true
    default_tier: "moderate"
    tiers:
      simple:
        max_score: 30
        model: "gpt-4o-mini"
        provider: "openai"
      moderate:
        max_score: 70
        model: "gpt-4o"
        provider: "openai"
      complex:
        max_score: 100
        model: "claude-sonnet-4-6"
        provider: "anthropic"

A simple classification request scores low and routes to gpt-4o-mini. A multi-tool reasoning task scores high and routes to claude-sonnet-4-6.

You can override the tier per request with the x-prism-complexity-override header. Pass the tier name (e.g., simple, moderate, complex - matching your configured tier names).

Provider lock (sticky routing)

Force a request to a specific provider, bypassing the routing strategy. Useful for stateful workflows where you need consistency across multiple calls.

Set it via the x-prism-provider-lock header or provider_lock in request metadata:

response = client.chat.completions.create(
    model="gpt-4o",
    messages=[{"role": "user", "content": "Hello"}],
    extra_headers={"x-prism-provider-lock": "openai"},
)

Configure which providers can be locked to:

routing:
  provider_lock:
    enabled: true
    allowed_providers: ["openai", "anthropic"]
    deny_providers: ["groq"]  # never lock to Groq

If allowed_providers is empty, all providers are allowed (except those in deny_providers).

Adaptive strategy details

The adaptive strategy learns from real traffic and adjusts weights over time:

1. Learning phase: For the first N requests (default: 100), uses round-robin to gather baseline latency and error data from all providers.
2. Active phase: Computes per-provider weights every 30 seconds using latency (lower is better) and error rate (fewer errors is better).
3. Weight smoothing: New weights are blended with old weights using a smoothing factor (default: 0.3) to prevent wild swings.
4. Minimum weight: No provider drops below 5% weight, ensuring all providers stay in rotation.

routing:
  default_strategy: "adaptive"
  adaptive:
    enabled: true
    learning_requests: 100
    update_interval: 30s
    smoothing_factor: 0.3
    min_weight: 0.05
    signal_weights:
      latency: 0.5
      error_rate: 0.4
      # cost: 0.1 (parsed but not yet used in weight calculation)

Race (fastest response) details

The fastest strategy sends the same request to all eligible providers simultaneously and returns whichever responds first. The rest are cancelled.

routing:
  default_strategy: "fastest"
  fastest:
    max_concurrent: 3        # limit parallel calls
    cancel_delay: 50ms       # wait before cancelling losers
    excluded_providers:       # skip these in the race
      - "groq"
